Do not rotate past position shown or severe piston and valve damage can occur. Severe piston and valve damage will occur.ĬAUTION:Rotate the crankshaft counterclockwise only. Tighten the Camshaft Holding Tools to maintain camshaft pre-positioning.ĬAUTION:Unless otherwise instructed, at no time when the timing chains are removed and the cylinder heads are installed is the crankshaft or camshaft to be rotated. Rotate the RH camshaft with the Camshaft Positioning Tool until the timing mark is approximately at 11 o'clock. Rotate the LH camshaft with the Camshaft Positioning Tool until the timing mark is approximately at 12 o'clock. NOTE:Slightly loosen the camshaft holding tools to allow slight camshaft movement.
286: Installing Camshaft Positioning Tool 284: Identifying Timing Marks On Timing ChainĬAUTION:Do not turn the engine over with the camshaft positioning tool or damage to the camshaft sprocket or the bolt can occur.įig. If the copper links are not visible, mark two links on one end and one link on the other end, and use as timing marks.įig. 283: Installing Retaining Clip On Tensioner To Hold Plunger In During Installation
#Coyote timing install#
Install a retaining clip on the tensioner to hold the plunger in during installation.įig. 282: Compressing Tensioner Plunger, Using A ViseĬompress the tensioner plunger, using a vise. ĬAUTION:Timing chain procedures must be followed exactly or damage to valves and pistons will result.įig. please re-post with any diagrams you require to see ? this is a very big job. There are too many diagrams for me to show them all.
